Description
Digital Yacht's WLN30 Smart is a new NMEA WIFi server for integrating tablets and mobile devices with navigation systems. This server enables applications and software to display and calculate information in real time. The Smart WLN10 creates a password-protected onboard Wi-Fi
When this server is connected to an AIS system, AIS targets will be displayed in real time on compatible applications such as NavLink, Weather4D, TimeZero, iAIS, SailGrib, SeaPilot and many others.
This new version of the WLN30 can now be programmed via a simple web page to set the speed of the NMEA0183 interface (4800 or 38400 baud) and to make the initial configuration: Open a web page and enter the IP address of the product, then you can configure the NMEA0183 interface (38400 or 4800 baud), the Wi-Fi name and the password. Programming made easy!
The Smart WLN30 supports UDP (up to 7 devices at the same time) and TCP/IP protocols for maximum application compatibility. This server is bidirectional, so certain applications and software can directly control the autopilot.
The Smart WLN30 has 3 NMEA0183 inputs, so you can add our Seatalk-NMEA adapter to broadcast data from Seatalk instruments via Wi-Fi using the Smart WLN10
SPECIFICITIES
NMEA0183 server and Wi-Fi (4800 baud or 38400 baud)
Web interface used for programming and initial configuration
NMEA0183 interface, Wi-Fi name and password are configurable
Supports UDP and TCP/IP protocols
7 devices can receive data at the same time
Display received NMEA data in the web interface
Bi-directional Wi-Fi interface
Fully compatible with most navigation applications and software
Easy-to-install IPX4 enclosure
3 inputs/outputs NMEA0183
When this server is connected to an AIS system, AIS targets will be displayed in real time on compatible applications such as NavLink, Weather4D, TimeZero, iAIS, SailGrib, SeaPilot and many others.
This new version of the WLN30 can now be programmed via a simple web page to set the speed of the NMEA0183 interface (4800 or 38400 baud) and to make the initial configuration: Open a web page and enter the IP address of the product, then you can configure the NMEA0183 interface (38400 or 4800 baud), the Wi-Fi name and the password. Programming made easy!
The Smart WLN30 supports UDP (up to 7 devices at the same time) and TCP/IP protocols for maximum application compatibility. This server is bidirectional, so certain applications and software can directly control the autopilot.
The Smart WLN30 has 3 NMEA0183 inputs, so you can add our Seatalk-NMEA adapter to broadcast data from Seatalk instruments via Wi-Fi using the Smart WLN10
SPECIFICITIES
NMEA0183 server and Wi-Fi (4800 baud or 38400 baud)
Web interface used for programming and initial configuration
NMEA0183 interface, Wi-Fi name and password are configurable
Supports UDP and TCP/IP protocols
7 devices can receive data at the same time
Display received NMEA data in the web interface
Bi-directional Wi-Fi interface
Fully compatible with most navigation applications and software
Easy-to-install IPX4 enclosure
3 inputs/outputs NMEA0183
